Cellular Wired Gateway
Product Specifications
Parameter | Specification |
Model No. | DK-MIGW-2102 |
Support Model | 7 modes are supported: B1 / B3, B5 / B8 @ FDD LTE B34 B38 / B39 B40 / B41 @ TDD LTE B1 / B8 @ WCDMA B34 / B39 @ td-scdma BC0 @ CDMA2000 1 x/EVDO B3 / B8 @ GSM Including 4G and 3Gnetworks. |
Transmission Rate | LTE-FDD:Max 150Mbps (download) /Max 50 Mbps (uplink)
LTE-TDD:Max130Mbps (download) /Max 30 Mbps
(uplink) WCDMA:384Kbps (download) /Max384Kbps
(uplink)
TD-SCDMA:Max 4.2Mbps (download) /Max 2.2 Mbps
(uplink) EDGE:296Kbps (download) /Max236.8Kbps
(uplink) GPRS:107Kbps (download) /Max85.6Kbps
(uplink) |
SIM Card | Voltage: 3V, 1.8V; Size: Big Card |
Antenna Interface | 50Ω/SMA glue stick antenna or sucker antenna |
Serial Port Type | RS-232/RS-485 |
Operating
Temperature | 40~85°C |
Running
temperature | 40~90°C |
Size | L×W×H=9.4cm×6.5cm×2.5cm |
